Download datasheetSignal generator for RF energy solutions
The product provides an all-in-one solution for the small signal generation in the RF energy solutions such as cooking and lighting markets.
The product facilitates RF energy design by:
- Allowing on-board integration
- Providing flexibility in system solution development
Features and benefits
- Support from 2400 MHz to 2483.5 MHz, from 902 MHz to 928 MHz and from 433 MHz to 434.8 MHz ISM bands
- Single 3.3 V supply voltage
- SPI-bus interface up to 20 MHz
- Fully integrated LC-VCO operating in the range from 6.6 GHz to 10 GHz and used with a Σ∆ PLL to generate the frequency
- Very fast tuning and hopping time PLL
- High frequency daisy chaining allowing coherent excitation of multiple RF amplifier chains
- 360° phase shifter with 1.4° steps
- Medium Power Amplifier (MPA) delivering an output up to +27 dBm peak power (max. +24 dBm for continuous use)
- Low Power Amplifier (PPA) delivering an output up to +7 dBm
- Integrated 20 dB gain control
- Integrated RF switch allowing PWM control
- Temperature sensor indicates the junction temperature of the die
- RoHS compliant
Applications
- Solid-state cooking
- Solid-state lighting
Parametrics
Symbol | Parameter | Conditions | Min | Typ/Nom | Max | Unit | Function |
---|---|---|---|---|---|---|---|
frange | frequency range | 433 | 2500 | MHz | |||
Test signal: CW @ 2450 MHz | |||||||
frange | frequency range | 2400 | 2483.5 | MHz | PLL | ||
tset | setting time | 50 | μs | PLL | |||
ts(f) | frequency settling time | from one frequency to another | 5 | 10 | μs | PLL | |
φn | phase noise | at 2483.5 MHz; at 100 kHz frequency offset | -87 | dBc/Hz | PLL | ||
∆φstep | phase shift step | 1.4 | ° | Phase shifter | |||
φRF | RF phase | 0 | 360 | ° | Phase shifter | ||
Eφ | phase error | absolute value step size error | 0 | 0.5 | 1 | ° | Phase shifter |
Eφ | phase error | cumulative phase error | 5 | ° | Phase shifter | ||
Po(max) | maximum output power | 24 | 27 | dBm | MPA | ||
αsp(ob) | out-band spurious attenuation | consider second and third harmonics only | -30 | dBc | MPA | ||
Pob | out-band power | integrated power outside the band of interest; fVCO(max) = frange max - 1 MHz; fVCO(min) = frange min + 1 MHz; rf_mpa_power[5:0] = 42 | -45 | dBc | MPA | ||
Po(range) | output power range | 20 | dB | MPA | |||
αisol | isolation | ON/OFF switch isolation | 40 | dB | MPA | ||
tsw | switching time | OFF/ON ramping transition | 700 | ns | MPA | ||
Zo | output impedance | 40 | Ω | MPA | |||
Po(max) | maximum output power | rf_mpa_power[5:0] = 63 | 7 | dBm | PPA | ||
Po | output power | rf_mpa_power[5:0] = 42 | 5 | dBm | PPA | ||
Po(range) | output power range | 30 | dB | PPA | |||
Zo | output impedance | 200 | Ω | PPA | |||
Test signal: CW @ 915 MHz | |||||||
frange | frequency range | 902 | 928 | MHz | PLL | ||
tset | setting time | 50 | μs | PLL | |||
ts(f) | frequency settling time | from one frequency to another | 5 | 10 | μs | PLL | |
∆αstep | phase shift step | 1.4 | ° | Phase shifter | |||
φRF | RF phase | 0 | 360 | ° | Phase shifter | ||
Eφ | phase error | absolute value step size error | 0 | 0.5 | 1 | ° | Phase shifter |
Po(max) | maximum output power | 24 | 27 | dBm | MPA | ||
Po(range) | output power range | 20 | dB | MPA | |||
αisol | isolation | ON/OFF switch isolation | 40 | dB | MPA | ||
tsw | switching time | OFF/ON ramping transition | 700 | ns | MPA | ||
Zo | output impedance | 40 | Ω | MPA | |||
Po(max) | maximum output power | rf_mpa_power[5:0] = 63 | 7 | dBm | PPA | ||
Po | output power | 5 | dBm | PPA | |||
Po(range) | output power range | 30 | dB | PPA | |||
Zo | output impedance | 200 | Ω | PPA | |||
Test signal: CW @ 433 MHz | |||||||
frange | frequency range | 433.0 | 434.8 | MHz | PLL | ||
tset | setting time | 50 | μs | PLL | |||
ts(f) | frequency settling time | from one frequency to another | 5 | 10 | μs | PLL | |
Po(max) | maximum output power | 24 | 27 | dBm | MPA | ||
Po(range) | output power range | 20 | dB | MPA | |||
αisol | isolation | ON/OFF switch isolation | 40 | dB | MPA | ||
tsw | switching time | OFF/ON ramping transition | 700 | ns | MPA | ||
Zo | output impedance | 40 | Ω | MPA | |||
Po(max) | maximum output power | rf_mpa_power[5:0] = 63 | 7 | dBm | PPA | ||
Po | output power | rf_mpa_power[5:0] = 42 | 5 | dBm | PPA | ||
Po(range) | output power range | 30 | dB | PPA | |||
Zo | output impedance | 200 | Ω | PPA |
Package / Packing
All type numbers in the table below are discontinued.
Type number | Package | Outline version | Reflow-/Wave soldering |
Packing | Product status | Marking |
Orderable part number, (Ordering code (12NC)) |
---|---|---|---|---|---|---|---|
BLP25RFE001 | HVQFN28 (SOT993-3) |
sot993-3_po | Reel 13" Q1/T1 | Withdrawn | Standard Marking |
BLP25RFE001Y (9349 601 73518) |
|
Tray, NonBakeable, Multiple in Drypack | Withdrawn | Standard Marking |
BLP25RFE001E (9349 601 73551) |
Discontinuation information
Pinning info
Pin | Symbol | Description | Simplified outline | Graphic symbol |
---|---|---|---|---|
1 | SSN | SPI-bus: Slave Select Not (from master) | ||
2 | n.c | not connected | ||
3 | CAPREG_VCO | VCO internal regulator filtering input | ||
4 | VDD(PLL) | PLL supply voltage; 3.3 V | ||
5 | GND(PLL) | PLL ground | ||
6 | LO_IN_P | high frequency daisy chaining positive input | ||
7 | LO_IN_N | high frequency daisy chaining negative input | ||
8 | VT | VCO input voltage | ||
9 | CP | charge pump output | ||
10 | LO_OUT_P | high frequency daisy chaining positive output | ||
11 | LO_OUT_N | high frequency daisy chaining negative output | ||
12 | REF_CLK_IN | external reference clock input | ||
13 | i.c. | internally connected | ||
14 | i.c. | internally connected | ||
15 | n.c. | not connected | ||
16 | n.c. | not connected | ||
17 | VDD(RF) | RF power supply; 3.3 V | ||
18 | PPA_OUT_P | RF low-power positive output | ||
19 | PPA_OUT_N | RF low-power negative output | ||
20 | MPA_LP_OUT_P | RF Intermediate supply for high-power first stage MPA positive path | ||
21 | MPA_LP_OUT_N | RF Intermediate supply for high-power first stage MPA negative path | ||
22 | MPA_HP_OUT_P | medium-power RF amplifier positive output | ||
23 | MPA_HP_OUT_N | medium-power RF amplifier negative output | ||
24 | SWITCH | RF switch control | ||
25 | GND(DIG) | digital ground | ||
26 | MISO | SPI-bus: Master Input Slave Output | ||
27 | MOSI | SPI-bus: Master Output Slave Input | ||
28 | SCLK | SPI-bus: Serial Clock (from master) | ||
- | Exposed die pad | connect to RF ground |
