BPC2425M9X250
Download datasheetPower LDMOS module
250 W LDMOS power module for Industrial, Scientific and Medical (ISM) applications at frequencies from 2400 MHz to 2500 MHz. The module is designed for high-power CW applications.
Features and benefits
- High efficiency
- Small size: 52 x 34 mm
- Input/output 50 Ω matched
- Designed for broadband operation (2400 MHz to 2500 MHZ)
- Built-in temperature sensor
- Built-in temperature compensation networks
- 100 % RF testing in production
- For RoHS compliance see the product details on the Ampleon website
Applications
- RF power amplifiers for CW applications in the 2400 MHz to 2500 MHz frequency range such as industrial heating and drying, scientific, medical, plasma lighting and solid state cooking
Parametrics
| Symbol | Parameter | Conditions | Min | Typ/Nom | Max | Unit |
|---|---|---|---|---|---|---|
| frange | frequency range | 2400 | 2450 | 2500 | MHz | |
| PL(1dB) | nominal output power at 1 dB gain compression | 280 | W | |||
| Test signal: CW | ||||||
| VDS | drain-source voltage | 2450 MHz [0] | 32 | V | ||
| Gp | power gain | 2450 MHz [0] | 17 | dB | ||
| ηD | drain efficiency | 2450 MHz [0] | 61 | % | ||
| PL | output power | 2450 MHz | 300 | W | ||
| Test signal: CW pulsed | ||||||
| VDS | drain-source voltage | 2450 MHz [0] [1] | 32 | V | ||
| Gp | power gain | 2450 MHz [0] [1] | 17.5 | dB | ||
| ηD | drain efficiency | 2450 MHz [0] [1] | 63 | % | ||
| PL | output power | 2450 MHz [0] [1] | 300 | W | ||
Package / Packing
All type numbers in the table below are discontinued.
| Type number | Package | Outline version | Reflow-/Wave soldering |
Packing | Product status | Marking |
Orderable part number, (Ordering code (12NC)) |
|---|---|---|---|---|---|---|---|
| BPC2425M9X250 | Pallet (Pallet) |
Tray, Multiple | Withdrawn | Standard Marking |
BPC2425M9X250Z (9349 601 38117) |
Discontinuation information
Pinning info
| Pin | Symbol | Description | Simplified outline | Graphic symbol |
|---|---|---|---|---|
| 1 | RF IN | RF input |
|
|
| 2 | RF OUT | RF output | ||
| 3 | VDA | drain-source voltage, pin A | ||
| 4 | VDB | drain-source voltage, pin B | ||
| 5 | VG | gate-source voltage | ||
| 6 | TEMP | temperature sensor |
